MAGPRO 80 4S
MAGNETIC CORE DRILLING MACHINE
Generous stroke of 10 5/8" (enables, among other things, the use of longer drills)
- 4 speeds
- Core drilling up to 3 1/8" and twist drilling up to 5/8"
- 17.000 N magnetic adhesion
- Overload protection
- Integrated cooling system
Scope of delivery: Lashing strap, coolant tank,
chip protection, eject wedge, tools, CM3 / Weldon 19 and carry case.
|
Power input
|
14 amps
|
| Voltage |
115 V / 60 Hz
|
| Magnetic adhesion | 17.000N |
|
Net weight
|
53 lbs /24 kg |
|
Reference
|
490184NA |
Data Sheet & Spare Parts
Technical specifications
| No load speed / full load speed |
1: 190 / 105 min-1 2: 300 / 165 min-1 3: 420 / 230 min-1 4: 660 / 365 min-1 |
|
Shank
|
3/4" / 1 1/4" mm Weldon, MT3
|
|
Core drill max. Ø x depth
|
1/2" - 3 1/8" x 3 15/16" |
|
Twist drill max. Ø x depth |
5/8" x 4 3/8" 1 1/4" x 5 15/16" |
|
Stroke
|
3 3/8" mm for standard core drilling up to 10 5/8" mm for twist drilling |
|
Magnetic base
|
8 5/8" x 4 3/8"
|
|
Coolant supply
|
integrated, automatic
|
Equipment
|
Products
|
Description
|
Reference
|
E-Shop
|
|
HSS-CO core drill set - 1" x Ø 9/16", 5/8", 11/16",3/4", 13/16", 15/16" + ejector pin 1/4"x3" |
490145IN |
|
|
|
HSS-CO core drill set - 30 mm x Ø 12, 14, 16, 18, 20, 22 mm + ejector pin |
490145
|
|
 |
"GOLD FINGER" core drill set TiN-coated - 1" x Ø 9/16", 5/8", 11/16",3/4", 13/16", 15/16" + ejector pin 1/4"x3" |
490145INTiN |
|
 |
"GOLD FINGER" core drill set TiN-coated 30 mm x Ø 12, 14, 16, 18, 20, 22 mm + ejector pin |
490145TiN |
|
|
Drill chuck 5/8" and MT3 adapter |
490164
|
|
|
Adapter Weldon 3/4" / Fein Quick-in
|
490154
|
|
|
Magnetic Chip Collector
|
490153
|
|
|
High performance cutting oil spray (400 ml)
|
490020
|
|
| PIPEFIX for pipes Ø 5 7/8" - 19 5/8" (150 mm - 500 mm) |
490010BIG | ||
